JSW Series Three Phase Purified Ac Voltage Regulator

  • 30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)
  • 30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)
  • 30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)
  • 30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)
  • 30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)
30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)

30kVA Full Automatic Three Phase Purified AC Voltage Regulator (Model: JSW-30kVA)

  • Input Voltage: 310~450VAC or Customized
  • Output Voltage: 220V+/-1% (L-N) or Customized
  • Load effect: ≤+/-1%
  • Efficiency: >95% (Full load)
  • Description: 30kVA Full Automatic Three Phase Purified AC Voltage Regulator
  • INQUIRY   EMAIL
JSW Series Three Phase Full automatic Purified AC Voltage Regulator





Summary



JSW series precision purification three phase AC constant current is composed of JJW series single phase power supply through "star" connection, so it have all the advantages of single phase power supply. Overvoltage (undervoltage) protection, overload protection, phase loss protection and other functions. It is an ideal regulated power supply for production enterprises, scientific research units, medical and health fields, various test equipment, measuring equipment, and electronic equipment.


Product Performance


Power Range
3KVA-100KVA (three phase)
Input Voltage
Ordinary 310~450V +/-3%, or optional larger range
Output Voltage
Ordinary 380V or customized
Output Accuracy
220V±1%
Power source volt. effect
≤±1%
Display
Ordinary pointer display, LED or LCD display screen can be customized
Frequency
50Hz/60Hz
Response time
30~60ms
Load effect
≤±1%
Waveform Distortion
≤5% (Additional)
Efficiency
>92% (full load)
Ambient Temperature
-5 ~ +40°C
Relative Humidity
≤95%
Peak absorption
Input 3000V/3us peak output ≤ 30V
Over-voltage alarm protection
phase voltage 246V+/-4V,  line voltage 425V+/-7V




Specifications, Size, Weight
